Honeywell PD45
Label printer, mid-range printer, thermal transfer, 8 dots/mm (203dpi), media width (max.): 114mm, print width (max.): 108mm, roll diameter (max.): 203mm, ribbon core: 25.4mm, speed (max.): 200mm/sec., USB (type B), USB host, emulation: ZPLII, ZSim II, IPL, DPL, RAM: 128MB, Flash: 128MB, black mark sensor, gap sensor, order separately: Power cable-
Versandkostenfrei ab 59 Euro
-
Mehr als 20 Jahre Erfahrung in der Auto-ID-Branche
Top features of the Honeywell PD45S
- Highest precision: Thanks to patented dual sensor technology with a positioning accuracy of ±0.5 mm
- Robust all-metal housing: Durable, easy to maintain and ideal for industrial environments
- Smart printing & versatile connectivity: Direct printing without a PC, flexible interfaces including WLAN, GPIO and more.
Industrial printer with maximum efficiency: The Honeywell PD45S
The Honeywell PD45S is a latest-generation industrial label printer that has been specially developed for demanding applications in production, logistics, healthcare, retail and the public sector. With its robust metal housing, state-of-the-art printing technology and user-friendly design, it sets new standards in terms of performance and reliability. A key feature of the PD45S is its smart printing capability: users can make printer settings directly from the device - without the need for a PC or additional software. Apps run directly on the printer, making configurations particularly flexible and efficient.
Technical precision and reliability in any environment
The PD45S impresses with its exceptional print accuracy: with its patented dual-sensor positioning technology, the printer achieves a vertical positioning accuracy of up to ±0.5 mm with a minimum label height of just 5 mm. This technology ensures that even the smallest labels are positioned precisely and printed error-free - ideal for demanding industrial processes. The powerful 800 MHz ARM Cortex-A7 processor and 256 MB RAM ensure fast data processing and smooth printing processes. The printer supports both direct thermal and thermal transfer printing - and can therefore be used flexibly for different media and applications.
Ergonomics, expandability and global usability
In addition to its technical performance, the PD45S impresses with its well thought-out design: A large viewing window makes it easy to monitor consumables, while consumables such as the print head or sensors can be replaced quickly without tools. The PD45S also leaves nothing to be desired in terms of connectivity: In addition to USB and Ethernet connections, the printer supports optional interfaces such as WLAN, parallel connections, GPIO modules and industrial interfaces for maximum integration options. Thanks to extensive language support and compatibility with Windows, Linux and SAP systems, the Honeywell PD45S is ready for immediate use worldwide - a true global player among industrial printers.
| Printing process | Direct thermal and thermal transfer |
| Print resolution | 203 dpi (8 dots/mm) / 300 dpi (11.8 dots/mm) |
| Print speed | Up to 250 mm/s (203 dpi) / up to 200 mm/s (300 dpi) |
| Max. Print width | 108 mm (203 dpi) / 105.7 mm (300 dpi) |
| Min. label height | 5.0 mm |
| Positioning accuracy | ±0.5 mm (patented dual sensor technology) |
| Processor | ARM Cortex-A7, 800 MHz |
| Memory | 256 MB Flash, 256 MB DDR3 SDRAM |
| Display | 3.5" color touch screen (PD45S0F) / 2.36" LCD with buttons (PD45S0C) |
| Dimensions (LxHxW) | 438 x 270 x 249 mm |
| Weight (LxHxW) | 9.34 kg (PD45S0F) / 9.25 kg (PD45S0C) |
| Interfaces (standard) | USB 2.0 Host & Device, Ethernet, RS-232 |
| Optional interfaces | WLAN, parallel, GPIO, serial ports, peeler, rewinder, cutter |
| Media width | 20 mm - 114 mm |
| Label length (min.) | 5 mm (tear), 12.7 mm (peel), 38 mm (cutter) |
| Roll diameter max. | 203.2 mm |
| Operating temperature | +5°C to +40°C |
